Product:
Nickel Foam
Formula:
Ni
CAS No.:
7440-02-0
Product No.:
SP1253
Package:
In terms of customer's requirements.

Description

1.Ultra light weight: it has a large specific surface area. The specific gravity is 0.2 ~ 0.3, which is 1 / 4 of water, 1 / 3 of wood, 1 / 10 of aluminum and 1 / 30 of iron. It is ultra light in weight.

Sound absorption: the porous structure has the sound absorption characteristics of wide frequency. High temperature resistance above 1100 ℃, acid and alkali corrosion resistance, good permeability, uniform pore structure, fast heating and heat transfer.

2.Electron wave shielding: through the relatively thin thickness, it can shield about 90dB electron wave.Processability: can cut, bend and simply stick.Fire resistance: keep stable shape, difficult to burn at high temperature, high temperature resistance.Thermal conductivity: porous materials have strong thermal conductivity.

3.Air permeability: homogeneous three-dimensional network structure, has the function of filtration, gas, fluid flow stability. Sound insulation: through additional treatment, it can intercept a high noise and has good sound insulation effect.



Specification

ITEM

SPECIFICATION

Aperture

0.1mm-10mm

PPI

5-120ppi

Porosity

50%-98%

Through hole ratio

≥98%

Volume density

0.1-0.8g/cm³

Thickness(mm)

0.3-0.5-1.0-1.5-1.6-1.7-1.8-2.0-2.5-3.0-4.0-
5.0-6.0-7.0-8.0-9.0-10-15-20-25-30-35-40-45

Width(mm)

0-500mm

In terms of customer's requirements



Applications and Usages

Carrier materials of tail gas purifier, battery electrode materials, various catalyst carriers, especially filter materials requiring high temperature resistance and acid-base corrosion, surface materials of infrared burners, heating materials of various industrial and civil drying equipment, etc.
