Description

Sound absorption: porous structure, which can produce diffuse reflection and microporous silencing of sound waves, so as to achieve silencing effect

Specific surface area: under the same through-hole rate, it has the largest specific surface area compared with other porous materials

Electromagnetic shielding: it has a good shielding effect on a certain range of electromagnetic waves

Processing performance: it can easily carry out machining such as cutting, stamping and bending

Fire resistance: high temperature resistance above 1100 ℃, stable shape and not easy to burn

Strong thermal conductivity: uniform pore structure and fast heating and heat transfer

Permeability: the flow stability of gas and fluid is super strong, which can be used for filtration

Corrosion resistance: resistant to various acid and alkali corrosion



Specification

ITEM	SPECIFICATION	RESULT
Thickness range	1-40mm	Confirmed
PPI scope	10-140	Confirmed
Porosity	95-98%	Confirmed
Through hole ratio	≥98%	Confirmed
Aperture	0.3mm-7mm(10-140ppi)	Confirmed
Area density	100-15000g/m2	Confirmed
Bulk density	0.1-2.0g/cm3	Confirmed
Size	1000×1000(MAX)	Confirmed



Applications and Usages

Chemical Engineering:

Catalyst and its carrier, filter medium and medium in separator (such as oil-water separator and automobile exhaust purification

Carburetor, air purifier, etc.)

Thermal field:

Damping material, high efficiency heat conducting material

Functional material field:

Silencing, vibration absorption, cushioning, electromagnetic shielding, stealth technology, flame retardant, thermal insulation, etc

Industry:

Industrial filter materials, high-grade decorative materials, industrial filter screen
