ITEM

SPECIFICATION

Thickness

113um

Width

400mm

Length

7.5m/roll

Surface quality

Mat finish

Pinholes

Subject to the applicable alumium foil standard

Impurity

1mm or less in diameter

Fish Eye

2mm or less in diameter(clear),1mm or less in diameter(colored)

Moldin depth

≥5.0mm

Hot sealing Coniditon

180-190℃

Moisture Vapor/O2 Transmission Rate

200ppm/5years

Laminate Strength

Nylon/AI more than 2N/15mm AI/CPP more than 5N/15mm
More than 22.5N/15mm wide at 200℃×0.2Mpa×2sec by TOB

Heat Seal Strength

Heat sealing

Solvent Retention

Less than 5mg/m2

Appearance

Within the sample of the limit

Slip Factor

CPP/CPP less than 1.0
